PNI MAB300 swing gate automation kit with 2 40W motors, remote controls and control panel, photocells and lamp, gate length 2 x 2.5m max, gate weight 200Kg

Swing gate automation system

The swing gate opening automation kit is equipped with two 40W motors with a maximum rotation speed of 200rpm that can open or close gates with a maximum weight of 200 kg and a maximum length of 2.5 meters. The PNI MAB300 gate automation kit includes the basic components necessary to put a practical access control system into operation: control unit, two piston motors (maximum extension 300 mm), two remote controls, two photocells, warning light, rubber stopper and mounting accessory kit.

Remote control, compatible devices

The gate can be opened and closed by remote control. The system supports the connection of other access control devices such as electromagnetic gates, hold-open electromagnets, access buttons, access keypads. Optionally, the system can be connected to a solar system or a 24V backup battery.

Automatic closing with delay

The system can be set so that the gates close automatically after a certain time interval. The gates can also open or close simultaneously or at a maximum difference of 10 seconds from each other or only one gate out of two can be opened.

Obstacle detection

In the event of an obstacle being detected during opening or closing, the gates stop. Choose safety for your family.

Installation diagram - dimensions

You can adjust the opening angle of the gate according to the dimensions in the table.

- D - desired opening angle

- A and B - values must be observed exactly on the same horizontal line with the angle to obtain the correct opening.

The values in columns A, B, C, E and L are expressed in mm.

The values in column D are expressed in degrees.

The length of the fully closed/open piston is present in both the documentation, the picture and the manual.
