CB PNI ML100 antenna, length 100 cm, 26-30MHz, 250W, 125mm magnet included
High performance CB PNI ML100 antennaThe performance of the product is closely related to the technical characteristics of the antenna in ideal mounting and use conditions: SWR <= 1.1, maximum applied power 250 W continuously, impedance 50 Ohms, stainless steel, etc. | |
Communication distanceCommunication distance is another decisive factor in the acquisition and use of a CB antenna. Thus, the communication distance of maximum 12 km is reached in ideal working conditions: calibrated antenna, open field without obstacles, station with maximum legally allowed power of 4W and with a standard reception. Any obstacle such as hills, mountains, buildings, walls can reduce this distance. | |
Antenna lengthAntenna length is a very important factor that can influence the communication distance. Thus, the longer the antenna, the longer the range. The PNI ML100 antenna has a length of 110 cm (magnetic base included). | |
Magnetic baseThe 120 / PL magnetic base in the package is provided with a 4 m cable, enough to place the antenna on the dome, has a diameter of 125 mm and a strong magnet that gives the antenna stability even at high speeds. | |
Full packageThis kit is ready for assembly with the package: antenna, magnetic base with cable and PL259 plug, enclosure for calibration. All you have to do is mount the antenna on a magnetic base, connect it to a CB radio station and calibrate it for maximum performance. |
Video presentation |
|
CB PNI ML100 antenna EN |
Product identification | |
Product code | PNI-ML100 |
Tape | CB |
Product color (spike) | Silver |
General characteristics | |
Working frequency | 26 - 28 Mhz |
Number of channels | 90 |
Maximum applied power | 250W |
Minimum SWR in the center of the band | 1.0 |
Length | 100 cm (110 cm with base included) |
impedance | 50 Ohm |
Material | Stainless steel |
Tip connector | PL259 |
Hole diameter (mm) | 16 mm |
Cable length | 4m |
Weight | 1.2 Kg |
dimensions | 1000 x 150 x 40 mm |
I earn | 4 dBi |
Working distance | 12 km |
Operating temperature | -26 ° C ~ + 60 ° C |
The package contains | |
Radio station antenna | Yes |
RG58 cable | 4m |
PL259 plug | Yes |
Magnetic base | 125 mm |
![]() PNI-ML100 |
|
