CB antenna PNI ML75, foldable, 26-28MHz, 300W with magnetic base included, length 90cm
PNI-ML75FC - PNI ML75 CB antenna, length 75cm, 26-28MHz, 300W, foldable, without accessories
| CB antenna without cableThe PNI ML75 CB antenna operates in the 26-28 MHz frequency range. It is 75 cm long and can communicate over a distance of up to 8 km (under ideal conditions of use). The PNI ML75 is perfect for drivers of TIRs, trucks or cars who want a product that ensures good communication in traffic. The SWR of less than 1.2:1 and the maximum supported power of 300W (for a short time) are essential specifications that recommend this product to the most demanding users. |
PL type threaded antennaWhen choosing a CB antenna, the following aspects must be taken into account:
The CB antenna is very important in the station-antenna assembly because the quality of the emitted and received signal depends on it. The PNI ML75 CB antenna is one of the few PL antennas that can be tilted 90 degrees to enter low-height passages, garages or parking lots. |
|
| Compatible PNI accessoriesThe PNI ML75 CB antenna with ø16mm thread is compatible with all PL type magnetic bases. For example: PNI 145/PL and with fixed mounting supports:
|
PNI-145-PL - Magnetic base PNI 145/PL 145mm contains 4m cable and plug PL259
Magnetic baseThe PNI 145/PL magnetic base has a diameter of 145 mm, a size that gives the antenna stability even at high speeds, having a pleasant design. |
|
| Threaded fasteningThe PNI145/PL base is compatible with antennas that have an internal thread fastening system. |
Cable lengthThe length of the cable is an important factor in choosing a magnetic base. The base from PNI 145/PL has a quality cable with a length of 4 m, which allows placing the antenna on the dome of the car without any problem, and placing the cable so as not to disturb the passengers. |
|
| Strong magnetThe PNI145/PL base has a strong magnet for its size, which gives it a very good grip on the car dome, and resistance and stability even at high speeds. |
Plug PL259The PNI 145/PL magnetic base is equipped with RG58 coaxial cable and PL259 plug for direct connection to the station. |
|
| Rubber support includedIn order to protect the car dome from possible scratches, but without affecting the operation of the antenna in optimal parameters, the magnetic base 145/PL is provided with a thin and resistant rubber support, which also protects the connections and solders inside it from water. |
Video presentation |
|
CB antenna PNI ML75, length 75cm, 26 28MHz, 300W, foldable UK |
PNI-ML75FC - PNI ML75 CB antenna, length 75cm, 26-28MHz, 300W, foldable, without accessories | |
|---|---|
| Product identification | |
| Product code | PNI-ML75FC |
| Work tape | ? B |
| Product color (spike) | Silver |
| Coil color | Black |
| General characteristics | |
| Working frequency | 26 - 28 Mhz |
| Maximum power applied | 40 W continuous / 300 W for a short time |
| Minimum SWR in the center of the band | less than 1.2:1 |
| Length | 750 mm |
| Impedance | 50 Ohms |
| Material | Stainless steel |
| Connector type | PL |
| Hole diameter | 16 mm |
| Weight | 343 gr |
| size | 750 X 40 X 40 mm |
| Polarization | vertically |
| Working distance | 7 km |
| Operating temperature | -26°C ~ +80°C |
| tiltable | Yes, up to 90 degrees |
| The package contains | |
| Radio station antenna | Yes |
| Rubber support | Yes |
PNI-145-PL - Magnetic base PNI 145/PL 145mm contains 4m cable and plug PL259 | |
|---|---|
| Product identification | |
| Product code | PNI-145-PL |
| General characteristics | |
| Sole diameter | 145 mm |
| Full speed | 200 km/h |
| Weight | 730 g |
| Cable length | 4 m |
| Compatible antenna type | With internal thread |
| size | 15x15x6 cm |
| The package contains: | |
| Magnetic base | Yes |
| Cable | Yes, 4m |
| jack | Yes, PL259 |
 PNI-145-PL |
|
