CB PNI Escort HP 5500 radio station kit, 4W, 12V/24V, ASQ and PNI Extra 40 CB Antenna, SWR 1.0, fiberglass, with magnet

Simplicity for everyone

The PNI Escort HP 5500 CB radio station is ultra compact, measuring only 115 X 115 X 35 mm and can fit even in the smallest spaces.

Easy to install: just connect it to the cigarette lighter socket and the exterior CB antenna mounted on the car's dome.

The PNI Escort HP 5500 was designed with simplicity in mind, so that anyone can use it easily. The high-quality electret condenser encapsulated in the microphone provides clear and powerful sound.

Important functions - anti-noise: SQ, ASQ and RF Gain

The PNI Escort HP 5500 CB radio station allows for the most accurate control over the background noise specific to the CB band.

The analog adjustable SQ function with potentiometer and 5-level ASQ allow the user to filter and eliminate noise, making communication clearer.

The 7-level RF Gain function allows control over the reception frequency, reducing distortion.

Other features of the PNI Escort HP 5500 station : 4W transmission power, 12-24V power supply, 40 channels, AM/FM modulation, emergency channels 9-19, 6-pin microphone connector, additional jack for external speaker.

Multistandard and multiband CB station

By setting the norm and modulation, you can use the station in the United Kingdom (UK) and most European Union countries.

The PNI Escort HP 5500 is equipped with the main European bands ( EU, CE, UK, PL, dE, in, i0, l2 ).

NOTE, to modify the rule:

1. Turn off the radio; simultaneously press the PTT key + the UP key on the microphone while turning the radio back on

2. The LED corresponding to the A/F key lights up and the current rate appears on the screen.

3. Press the UP-DOWN keys to reach the desired rate, then restart the station or press the PTT key to exit the rate setting mode.

Discreet and efficient

The PNI Extra 40 antenna is the smallest CB antenna (it has a height of only 44 cm - base included) that can be mounted on both cars and vans or minibuses. Its small dimensions make it almost unnoticeable, easily confused with the radio antenna. The average reception distance is 7 km.

Easy installation

The PNI Extra 40 CB antenna is easy to install, by simply screwing the spike onto the magnet fixed to the car's dome. The antenna is pre-calibrated from the factory.

Antenna performance

The PNI Extra 40 antenna has the characteristics of a large antenna: SWR 1.0, impedance 50 Ohms, frequency 26-28 MHz.
