PNI Escort HP 9500 multistandard CB radio station, front speaker, ASQ, VOX, Scan, 4W, AM-FM, 12V - 24V power supply, cigarette lighter plug included

CB radio station with dual 12V/24V power supply, adjustable automatic squelch, cigarette lighter socket included.

£66.35

Availability: In stock

SKU

PNI-HP9500

	An excellent product equipped with everything you need to communicate in the CB band The PNI Escort HP 9500 is a reliable CB station that ensures clear communication over long distances. With AM and FM operation, multi-standard, 5-level automatic squelch and adjustable squelch, large multicolor illuminated display, the HP 9500 is equipped with all the basic functions necessary for CB band communication. The front panel has a 2-pin Kenwood connector for hands-free operation. VOX function The VOX function of the PNI Escort HP 9500 CB station only works when headphones with a microphone are connected to the 2-pin PNI-K port.
Multi-band CB station The PNI Escort HP 9500 CB station allows communication in the main European frequency bands. Set the standard for the country you are in by simply pressing the MODE/BAND key. The selected band (UK, EU, DE) will be displayed on the screen throughout the use of the station.
	Ultra-compact design, front speaker, 1 DIN mounting The PNI Escort HP 9500 has a robust, compact design, making this station easy to place in any space in the car. The package includes a 1 DIN case for mounting the station in the car dashboard. The HP 9500 is a reliable companion for car, truck, and lorry drivers.
Cigarette lighter plug included The PNI Escort HP 9500 CB station is powered by 12V or 24V. The detachable power cable and cigarette lighter plug required for power supply are included in the package.

Product Identification
Manufacturer	NIP
Product code	PNI-HP9500
Product Type	CB Radio Station
General characteristics
Pattern	Furniture
Emission band type	AM/FM
Channels	80 AM/FM
Frequency	26.965 - 27.405 MHz
Microphone type (pins)	6 pins
Speaker Audio Power	3 W
Sensitivity (20dB SINAD)	0.5μV(AM), 0.25μ V@12Db(FM)
Audio Signal Distortion	less than 5% @ 1KHz
Emission power	4 W
Modulation	2 KHz ±0.2%KHz(FM)
EEPROM Memory	Yes
Power supply	12 V / 24 V
Absorbed current	max. 1.8A
Dimensions (W x H x D / Weight)	187 x 56 x 85 mm / 786 g
1DIN Mounting	Yes
Special features
Channel Scan	Yes
ASQ	Yes, 5 levels
Keypad lock	Yes
Adjustable ASQ	Yes
Emergency channels	Yes
Multicolor Screen	Yes, blue, red, cool green, purple, cyan, warm green, light blue
VOX	Yes, only with the headset connected
Manual Squelch	Yes
Accessory connection	2-pin PNI-K plug
Operating temperature	-26°C ~ +80°C
Dim	Yes
Display	Yes
Rear Panel Connections
Additional speaker connection	Yes
Front Panel Connections
2-pin jack	Yes
The package contains
Radio station	Yes
Microphone	Yes
Support and screws for fixing radio station	Yes
Microphone bracket and screws	Yes
Power Cord	Yes
Lighter Plug	Yes
User Manual	Yes
Helmet	Yes, with 2 pins
1DIN mounting housing	Yes
Feeder
Mounting case	Yes
