CB radio station TTi TCB-900 EVO, DSS, SQ, Dual Watch, Mic Gain, 12V-24V with sticky pad Blue as a gift
DSS - Automatic Squelch |
|
|
The CB TTi TCB-900 EVO radio station product is equipped with an automatic squelch system also called Dynamic Squelch System, extremely performant, which allows a very good filtering of conversations and receptions from CB (Citizen Band) |
|
Dual Voltage |
|
|
An advantage of this product is the dual power supply at both 12 V and 24 V which allows it to be used in both cars and trucks, dump trucks, coaches that have a 24 V electrical installation. |
|
Front Speaker |
|
|
The TTi TCB-900 EVO radio station is equipped with a front speaker, again an advantage if it will be mounted on the dashboard, or in the front panel of the cab of a truck, truck, or coach. Thus, the sound is heard clearly and loudly, in the direction of the user. |
|
Format 1 DIN |
|
|
The case format is 1 DIN identical to classic car cassette recorders. This makes it suitable for specially designed spaces, which can be found in cars as well as in trucks, dump trucks and coaches. |
|
Multi-Band |
|
|
Now radio amateurs can also benefit from the advantages of this product, the TTi TCB-900 radio station having 11 bands usable in Europe and beyond. |
|
VOX function |
|
|
The VOX function with which this station is equipped allows hands-free communication, the microphone capturing the voice remotely. The function is also accompanied by a very useful sensitivity adjustment in case the distance from the microphone varies. |
|
Special functions |
|
|
The TTi TCB-900 EVO radio station has, in addition to the classic functions, a series of special functions that can help in the use of the product such as: ATT, Mute, Lock, BL, + a special menu with some additional settings. |
|
Ready to use |
|
|
The TTi TCB-900 EVO radio station allows immediate use. All you have to do is attach a calibrated antenna to it, connect it to the cigarette lighter socket of the car or directly to the battery and turn it on channel 22. The product comes with a station stand, microphone stand and mounting screws. |
|
| Product identification | |
| Manufacturer | TTi |
| Product Code | PNI-TCB-900EVO |
| Product Type | CB radio |
| General Features | |
| Model | Mobile |
| Band type | AM / FM |
| Channels | 40 |
| Frequency | 26.965 - 27.405 MHz |
| Microphone type (pins) | 6 pin |
| Audio speaker power | 2 W |
| Sensitivity (20dB SINAD) | 0.7㎶ for 10dB (S+N)/N in AM mode / 0.7㎶ for 20dB SINAD in FM mode |
| Audio signal distortion | less than 8% @ 1KHz |
| Transmit Power | 4 W |
| Power supply | 12 V / 24 V |
| Absorbed current | max. 1.6A |
| Dimensions (W x H x H / Weight) | 170 x 90 x 50 mm / 764 gr |
| Mounting 1DIN | Yes |
| Special Features | |
| Dual Watch | Yes |
| Channel Scan | Yes |
| Mic Gain | Yes |
| ASQ | From |
| Key Lock | Yes |
| LCR - last selected channel | Yes |
| Adjustable ASQ | |
| Emergency channels | Yes |
| Multicolor display | Yes |
| VOX | From |
| Manual Squelch | Yes |
| Accessory connection | 1 pin plug |
| Operating temperature | -26°C ~ +80°C |
| Key sound | Yes |
| PTT (Push To Talk) | Yes |
| Display illumination | Yes |
| Key illumination | Yes |
| Rear panel connections | |
| Additional speaker connection | Yes |
| Bluetooth dongle connection | Yes |
| Package contains | |
| Radio | Yes |
| Microphone | Yes |
| Bracket and screws for radio | Yes |
| Microphone mounting bracket and screws | Yes |
| Power cable | Yes |
| Lighter plug | Yes |
| User manual | Yes |
| 1DIN mounting housing | |
