Bax with 10bc CB radio station kit PNI Escort HP 7120 ASQ, RF Gain, 4W, 12V and CB antenna PNI Extra 48 with magnet included, 45cm, SWR 1.0 AM/FM switched only in the EU band
PNI-7120EX48 - CB radio station kit PNI Escort HP 7120 ASQ, RF Gain, 4W, 12V and CB antenna PNI Extra 48 with magnet included, 45cm, SWR 1.0 AM/FM switched only in the EU band
Small dimensionsThe small dimensions of the station (only 110x120x28mm) allow it to be placed in the very narrow spaces of your car, without disturbing you while driving. |
|
| Emission power 4W. Power supply 12V.The PNI Escort HP 7120 CB station complies with the legislation in force in Romania and Europe, with a maximum allowed power of 4 W. It is powered at 12V using the cigarette lighter plug included in the package. |
FM/AMThe PNI Escort HP 7120 CB station allows communication in the FM band used in Romania, but also in the AM band used in some countries in the European Union. In addition to the band type, the station also allows selection of the norm (frequency band), a setting necessary for using the station in other countries in Europe. Default band: EC 40CH FM 4W. |
|
| Dual, adjustable and automatic digital squelchThe PNI Escort HP 7120 is enhanced with a digital automatic noise and interference reduction system (Digital Automatic Squelch). The manual and automatic double squelch mode offers 28 and 9 level adjustments along with the RF Gain function for finer reception adjustment. |
Discreet and efficientThe PNI Extra 48 antenna is among the smallest CB antennas (it has a height of only 45 cm) and can be mounted on both cars and vans or minibuses. Its small dimensions make it almost unnoticeable, easily confused with a radio antenna. The average reception distance is 10 km. |
|
| Aerodynamic designThe PNI Extra 48 antenna has a special anti-noise design that allows air to slide around the spike, eliminating wind noise. |
Video presentation |
|
PNI HP 6500 7120 ASQ FACTORY RESET enThe CB PNI Escort HP 7120 stationCB PNI Extra 48 antenna, with magnetic base, 45 cm, 26-30MHz, 150W, SWR 1.0, fiberglass |
| Product Identification | |
| Product code | PNI-7120EX48 |
| General characteristics of radio station | |
| Pattern | Furniture |
| Transmission band type | AM-FM |
| Frequency | 26.965-27.405 MHz |
| Channels | 40 AM/FM |
| Microphone Type | RJ11 |
| Speaker Audio Power | 1 W |
| Sensitivity (20dB SINAD) | greater than 1 μV (AM/FM) |
| Transmitting power | 4 W |
| Modulation | 80 - 90% |
| Installation 1 DIN | Yes |
| Power supply | 12 V |
| Consumption | 2A maximum |
| Dimensions / Weight | 110 X 120 X 28 mm / 385 g |
| Special radio station features | |
| Channel Scan | Yes |
| RF Gain | Yes, 9 levels |
| Keyboard lock | Yes |
| Multicolor display | Yes |
| Emergency channel button 9/19 | Yes |
| Adjustable ASQ | Yes, 9 levels |
| SQ - Squelch | Yes, 28 levels |
| Digital Automatic Squelch (ASQ) | |
| Operating temperature | -26 C - +60 C |
| Additional speaker connection | Yes |
| Radio antenna features | |
| Working frequency | 26 - 28 Mhz |
| Maximum applied power | 150 W |
| Minimum S.W.R. in the center of the band | 1,0 |
| Antenna length | 45 cm |
| Working distance | 10 km |
| Impedance | 50 Ohms |
| Material | Fiberglass |
| Connector Type | PL259 |
| Magnetic base included | Yes |
| Magnetic base diameter | 103 x 66 x 40 mm |
| Cable length | 4m |
| The package contains | |
| CB radio station | Yes |
| CB Radio Antenna | Yes |
| Magnetic base | Yes |
| PL259 Plug | Yes |
| RG58 Cable | |
| Cigarette lighter plug | Yes |
| Microphone support | Yes |
| Station support | Yes |
| RG174 Cable | Yes, 4 m |
