CB radio station PNI Escort HP 40 multistandard, 4W, AM, FM, 12-24V, ASQ, RF Gain

Multistandard CB radio station

The PNI HP40 is a CB communications equipment, designed to offer flexibility in use and compatibility with regulations in several countries.

The station offers a special function that allows the user to select the appropriate operating norm for the country they are traveling to.

This is crucial to be able to use the station under legal and optimal operating conditions in various regions, such as Europe, UK, Poland, Germany.

Complex functionality

The PNI HP40 CB radio station stands out for its extensive set of functions, such as: switching between AM and FM transmission modes, depending on the chosen standard, automatic channel scanning for quick identification of active communications, the Dual Watch function for simultaneous monitoring of two channels, and the adjustable automatic squelch function for eliminating unwanted noise.

The station also features a key lock function, useful for preventing accidental changes to settings, as well as visual information on the screen about the channel status, active functions and signal strength.

Advanced settings menu

The PNI HP40 CB radio station has a menu that gives the user access to numerous additional settings for customizing the operating mode.

Through this menu, parameters such as ASQ, VOX, RF Gain and VOX level and other operating options can be adjusted.

The user can select auxiliary functions and configure the station according to personal preferences.

Technical specifications

The PNI HP40 radio station operates in the CB band of 26.965 - 27.405 MHz, with 40 channels compatible with multinational standards and AM and FM emission modes. It is powered by 13.8 V or 27.6 V DC, being suitable for vehicles with a 12 V or 24 V system. Reception is ensured by a double-conversion superheterodyne system, with a sensitivity of approximately 110 - 114 dBm and an audio power of up to 3 W, and the transmission offers a transmission power of 4 W in both modes with distortions below 5%.
