CB radio station PNI Escort High Power 60 multistandard, FM/AM, 12V, ASQ, RF Gain
|
|
PNI Escort High Power 60 Radio StationPNI Escort High Power 60 is a station intended for use in CB bands, designed for mobile integration into vehicles or for fixed operations where 12 V DC power is available. The device offers full 27 MHz communications functionality, supporting AM and FM modulations and complying with regulatory standards for terrestrial band emissions. |
Power and installationThe unit is designed to operate exclusively on 12V DC voltage and includes reverse polarity protection to minimize the risk of damage during connection. For mounting, a bracket system and included screws are used, and external connections, including antenna and microphone, are standardized for wide compatibility. It is essential to install the antenna correctly and calibrate it for optimal performance. |
|
|
|
Functions, operation and controlThe station offers an extensive control interface with dedicated buttons for functions such as manual and automatic squelch (ASQ), channel scanning, AM/FM selection, Dual Watch, channel memory, Roger Beep tone emission, and VFO mode for direct frequency operation. The screen displays channel or frequency information, active function status, and received/transmitted signal levels. Secondary functions are accessible via a key combination and provide a high level of customization of the station's behavior. |
Relevant technical specificationsTechnically, PNI Escort High Power 60 operates in the frequency range 26.965 – 27.405 MHz with an antenna impedance of 50 Ω. The transmit power is 4 W, with frequency accuracy ±300 Hz and very low out-of-band interference levels (< 4 nW). In receive mode, sensitivity and selectivity are calibrated for good performance in heavy radio traffic conditions, and audio response is tailored for clarity in both types of modulation. |
|
|
|
Compatibility and regulationThe station complies with the European directives applicable to radio equipment (including RED 2014/53/EU), which ensures compatibility with the operating rules of most EU countries. |
| Product Identification | |
| Manufacturer | PNI |
| Product code | PNI-HP60 |
| Product Type | CB Radio Station |
| General characteristics | |
| Model | Furniture |
| Channel | 40 |
| Frequency | 26.965 - 27.405 MHz |
| Microphone type (pins) | 6 pins |
| Speaker Audio Power | 3 W |
| Sensitivity (20dB SINAD) | 113 dBm FM / 103 dBm AM |
| Emission power | 4 W |
| Hi/Low Power Selection | Yes |
| Power | 12 V |
| Absorbed current | 9 A |
| Dimensions (W x H x D / Weight) | 168 X 160 X 48 mm 1313 g |
| 1DIN Mounting | Yes |
| Special features | |
| Dual Watch | Yes |
| Channel Scan | Yes |
| Keypad lock | Yes |
| Roger Beep | Yes |
| Noise Filter | NB (Noise Blanker) |
| Channel Memory | Yes, 8 memoirs |
| Echo function | Yes |
| CTCSS / DCS (encoder/decoder) | Yes |
| Digital Automatic Squelch (ASQ) | Yes |
| Manual Squelch | Yes |
| TOT (Time out Timer) | Yes |
| Emergency function | Yes |
| BCL (Busy Chanel Lockout) Function | Yes |
| Rear Panel Connections | |
| Additional speaker connection | Yes |
| Port micro USB | Yes, for programming cable connection |
| The package contains | |
| Radio station | Yes |
| Microphone | Yes |
| Bracket and screws for fixing radio station | Yes |
| Microphone bracket and screws | Yes |
| Power Cord | Yes |
| Lighter Plug | Yes, definitely 16A |
| User Manual | Yes |
