UHF antenna PNI UF500

UHF antenna PNI UF500, 63 cm, 430-470 MHz, with cable PNI T941

UHF antenna PNI UF400, 47 cm, 430-470 MHz, with magnetic base 120 mm

UHF antenna PNI UF400, 47 cm, 430-470 MHz, with magnetic base 120 mm
£30.58
Availability: In stock
SKU
PNI-UF400

UHF antenna PNI UF400

UHF radio antenna

Radio antenna operating in the 430-470 MHz frequency range, suitable for both cars and trucks, compatible with all UHF 430-470 MHz radio stations on the market. Very easy to install thanks to the included magnetic base.

Installed on the car dome, the PNI UF400 offers maximum communication range and perfect omnidirectional coverage.

The PNI UF400 is compatible with the PNI Escort HP 446 UHF radio station.

Magnetic base 120 mm

The PNI UF400 antenna has a strong magnet, compact dimensions and 120 mm in diameter. The base is constructed of high quality materials, glossy ABS plastic and a galvanized metal coating to prevent corrosion.

The magnetic base comes with a 4 meter RG58 coaxial cable and PL259 plug for connecting the antenna to the radio station.

Magnetic base mobile antennas provide excellent performance when installed on the roof of a vehicle. Installation is incredibly easy. Simply place the magnet on the car dome and then route the coaxial cable into the car (through a window, door frame or hole) to connect it to the radio station.

UHF antenna PNI UF400

UHF antenna PNI UF400

Resistance to wear, bending and corrosion

The antenna wire is made of the best stainless steel, which resists bending and rust.

Also, the antenna coil has an anti-corrosion coating with excellent properties of resistance to external agents.

Video presentation

UHF radio station PNI Escort HP 446

UHF antenna PNI UF400 with magnetic base 120 mm UK

Write Your Own Review
You're reviewing:UHF antenna PNI UF400, 47 cm, 430-470 MHz, with magnetic base 120 mm
Your Rating
Product identification
Producer PNI
Product code PNI-UF400
Characteristics
Antenna type 1/4 λ
Work tape UHF
Frequency 430-470 MHz
Minimum SWR in the center of the band less than 1.5:1
Maximum power supported 400 W
Impedance 50 Ohms
I earn 6 dBi
Polarization
Connector PL
Hole diameter 22 mm
Wire material Stainless steel
Length 475 mm
Package contents
Antenna Yes
Magnetic base Yes, 120mm
RG58 cable Yes, 4 m
Plug PL259 Yes



PNI-UF400
Lang Type Name Link
EU10 User manual User manual EU10 Link
