Parking Sensors with PNI Mirror Display Escort P05 A and Reversing Camera

Parking sensors with mirror display and 18.5 mm reverse camera
£46.53
Availability: Out of stock
SKU
PNI-P05A

00022

performances

The PNI P05 kit contains a reversing camera that transmits the images taken from behind the car to the heliomatic mirror, thus facilitating the driver's orientation among possible obstacles. It is equipped with 4 high-performance sensors that detect obstacles in the area where they are directed. The number of 4 pieces allows a very good coverage of the area behind the car when reversing, thus eliminating the risk of hitting obstacles hidden from the classic visual field.

sensors

The PNI P05 parking sensors have a range of action between 0.3 and 2 m. The sensors are automatically activated when the car is put into reverse gear. Sensors are fixed in the back bar of the car, drilling the bar with the help of the special drill head included in the kit.

0054584

5154

General characteristics


Supply voltage 10.5 - 16 V cc
Nominal current 20 mA - 200 mA
Detection distance 0.3 - 2 m
Ultrasonic frequency 40 KHz
Operating temperature -30 ° C - + 70 ° C

Full package

Mirror with LCD display
Central unit
Parking sensors 4 pcs.
Reversing camera
Drill bit

42475

Video presentation

Parking sensors with PNI mirror display Escort P05 A and reverse camera

Write Your Own Review
You're reviewing:Parking Sensors with PNI Mirror Display Escort P05 A and Reversing Camera
Your Rating
Product identification
Producer PNI
Product code PNI-P05A
Color Black
General characteristics
Supply voltage 12V
Detection distance 0.3 - 2.5 m
Ultrasonic frequency 40 KHz
Operating temperature -30 ° C - + 75 ° C
Drilling cutter diameter Sensor cutter: 22mm Camera cutter: 18.5mm
Display 4.3 inches
Reverse camera features
Resolution 480x234
Diameter 18.5mm
feeding 12 V
The package contains
Mirror with LCD display Yes
Central unit Yes
Parking sensors 4 pcs.
Reversing camera Yes
Drill bit Yes
Video cable 6 m
Buzzer Yes



PNI-P05A
Lang Type Name Link
EU Declaration of Conformity Declaratie de conformitate RO, EN, HU, PL Link
EU10 User manual User manual EU10 Link
RO Declaration of Conformity DC&CG RO, EN, HU Link
