MP5 player Clementine 9545 1DIN display 4 inch, 50Wx4, Bluetooth, FM radio, SD and USB, 2 RCA video IN / OUT

MP5 4-inch auto display player, Bluetooth, FM radio, SD and USB, video input

£44.81

Availability: In stock

SKU

PNI-MP5-9545

Bluetooth The PNI Clementine 9545 MP5 player is equipped with the Bluetooth function that will allow you to make / receive phone calls or play audio files through the vehicle's audio system.
	Playback of multimedia files from external storage media You have multiple possibilities to play your favorite video, audio or photo files, from any of the 3 input sources: USB, micro SD card or Aux In.
Video in / out The PNI Clementine 9545 MP5 player has two RCA plugs: one AV-in or out and one AV-in for the reversing camera.
	External monitor connection The upper RCA jack on the rear panel can be video input or video output. The PNI Clementine 9545 MP5 player allows the transmission of the video image to an external monitor (headrest, car ceiling light). The image does not appear simultaneously on the player screen and on the external monitor. As long as the AV-out function is active, the monitor screen remains black. The lower RCA socket allows the connection of a reversing camera.
4 inch screen PNI Clementine 9545 has a 4-inch color LCD screen (800X480px) that gives you information about the different modes in which it can operate: FM radio mode, Media mode (USB or SD), AUX mode, Bluetooth mode.
	Universal ISO sockets PNI Clementine 9545 comes equipped with international standard ISO coupling plugs, which are found on most cars equipped with radio function from the factory.

Video presentation
The MP5 PNI Clementine 9545

Product identification
Producer	PNI
Product code	PNI-MP5-9545
Characteristics
Supply voltage	12V DC
Impedance	4 ohms
Maximum audio power (W)	4x50
Radio	AM/FM
FM radio	87.5 – 108.0 MHz
AM radio	522kHz - 1620kHz
USB	Yes, 2.0
Slot card	Yes, SD
Signal to noise ratio	greater than 40dB
Dimensions (W x H x D / Weight)	178 x 50 x 110 mm / 0.627 kg
Current consumption (max)	10
Audio input	AUX In (3.5mm mini jack)
fitting	1 DIN
Screen lighting, buttons	Red
Other connections	1 x RCA Video Input / Output 1 x RCA Video Input for the reverse camera
Special functions	Full HD 1920 x 1080px video playback
Preset radio memories	FM - 18 stations
Radio search mode	Automatic, manual
Screen	LCD, 4 inches
Play files	MP5, MP3, MP4, WMA, WAV etc.
Operating temperature	-26°C ~ +80°C
Bluetooth	Yes
The package contains:
Radio MP3 player	Yes
Mounting rail	Yes
Remote	Yes
Connection cables	Yes
User manual	Yes

PNI-MP5-9545

Lang	Type	Name	Link
EU	Declaration of Conformity	Declaratie de conformitate DE, EN, ES, FR, HU, IT, PL, RO	Link
EU	User manual	User manual EN-DE-ES-FR-HU-IT-PL-RO (old firmware)	Link
EU10	Declaration of Conformity	Declaration of conformity EU9	Link
EU10	User manual	User manual (new firmware) EU10	Link
