MAG150 automatic opening system for 2 x 150kg sliding doors
| Automatic system for sliding doorsThe MAG150 automatic opening system is the ideal solution for sliding doors, with the capacity to support weights of up to 2 x 150 kg. This system has an elegant design that integrates perfectly into any environment, offering functionality and comfort. It benefits from variable electrical power supply from AC90 to AC240V, which makes it versatile for various applications. In addition, its apparent installation facilitates adaptation to existing spaces, offering a practical and modern use for commercial or residential buildings. |
Advanced performance and connectivityThis system uses electric drive, which allows the doors to be opened remotely or automatically, thanks to human shape detection sensors. The running speed is adjustable, with an opening of up to 46 cm/s, guaranteeing fast and efficient operation. The open positioning time is also adjustable, allowing the user to customize the user experience according to specific needs. |
|
| Robust and versatile designMAG150 is designed to operate efficiently between -20°C and 50°C, making it ideal for a wide range of environmental conditions. Its dimensions suit both standard applications and custom solutions, with widths ranging from 650 mm to 1250 mm per door. This flexibility makes it suitable for various door types, including double doors with opposite opening, ensuring long-term durability. |
Practical uses in various scenariosThe MAG150 automatic opening system can be used effectively in various environments: in commercial institutions, shopping malls, office buildings, or even in homes. For example, store owners can implement this system to allow easy access for customers, while residential customers can benefit from comfort in daily use. It is also ideal for access configurations for people with reduced mobility, facilitating entry or exit without difficulty. |
|
| Easy installation and quick integrationThe MAG150 system comes equipped with all the necessary accessories for installation, including the control unit, drive motor and sensors. This allows for quick integration into any existing environment. With the help of the simple installation guide, each step is clearly defined, ensuring a quick and efficient implementation. In addition, technical support is available to assist users in the installation process, guaranteeing a stress-free experience. |
| Features Yala | |
| Supply voltage | AC90~240V, 50HZ |
| Actuation type | - electric for 2 doors - From remote control - On human form detection |
| Application mode | Apparent |
| Working temperature | -20°C ~ 50°C |
| Dimensions / Weight | Size 1 door: 650-1250mm Overall size: W=2600-5000mm |
| Rolling speed | Opening: 15 - 46 cm/s (adjustable) Closing: 13 - 46 cm/s (adjustable) |
| Open position time | 0-8s (adjustable) |
| Type door/doors | Double door with swing opening Maximum weight: 2 x 150 Kg |
| Package Contains | |
| Door locking kit | Yes |
| Accessories included | - Control and command unit - Drive motor - End wheel support - Switch module - 2 microwave sensors - 2 sensor cables - 2 sensor cables - 2 door frame connectors - 2 stop brackets - 2 remote controls with receiver - Drive belt |
