Yala hotel access control PNI CH2000R Gold with opening card reader on the right side

Yala hotel access control with card reader; opening on the right side. Only used in complete system with PNI FLH60 Programmer for PNC EMC-05 13.56 MHz PNI proximity cards for Yale hoteliers
£50.96
Availability: In stock
SKU
PNI-CH2000RG

PNI CH2000R Gold

Hotel access control

Yala PNI CH2000R offers a stand-alone solution for the security and access monitoring needs of a hotel, be it large, medium or small. The body of the yala is made of a galvanized alloy offering resistance to impact or blows. The door you want to install must have a thickness between 30 and 50 mm.

Electromagnetic card reader

PNI CH2000R offers the possibility of opening a door with the help of an electromagnetic card. It is also provided with a spare key, which can be used in emergency cases. From the inside, the yala has a manual opening mechanism. CH2000R is compatible with PNI EMC-05 13.56 MHz proximity cards.

Yala hotel access control PNI CH2000R Gold

Yala hotel access control PNI CH2000R Gold

opening

Opening on the right

Yala PNI CH2000R can be used to open a door to the right looking from the outside of the room, as in the attached image.

feeding

Yala PNI CH2000R is powered by 4 AA batteries. A set of batteries supports up to 10,000 openings. Yala gives a sound warning when the voltage drops below 4.8V, a sign that the batteries need to be changed.

Yala hotel access control PNI CH2000L

Yala hotel access control PNI CH2000L

Monitoring software

Yala PNI CH2000R can only be used together with the PNI FLH60 card programmer which also contains the monitoring software. Thus, you can configure a complex access control system.

Video presentation

The PNI CH2000L Electric lock offers a stand alone UK

Write Your Own Review
You're reviewing:Yala hotel access control PNI CH2000R Gold with opening card reader on the right side
Your Rating
Product identification
Producer PNI
Product code PNI-CH2000RG
Color Golden
General characteristics
feeding 6V (4 x AA alkaline batteries)
Maximum consumption 200mA
Material Zinc alloy
Anti-vandal Yes
Card reader EM card 13.56MHz
Mounting type Apparent
Dimensions/weight 244 x 77 x 26mm / 3.4kg
Operating temperature -20 ~ 50°C
Working humidity ≤ 80%
Opening type yala Left Inside / Right Outside
Action time less than 1 second
Door thickness 30 - 50mm
Card actuation distance 0 - 5 cm from the sensor
The package contains
Access control unit Yes
Installation and use manual Yes
Installation accessories Yes



PNI-CH2000RG
Lang Type Name Link
EU Declaration of Conformity Declaratie de conformitate EN, RO, HU, PL Link
EU User manual User Manual EN/ RO/ HU/ PL Link
EU10 Declaration of Conformity Declaration of conformity EU9 Link
EU2 User manual Quick guide RO, EN Link
RO Declaration of Conformity DC&CG Link
