Switching voltage source PNI ST105 input 230V AC, output 12V DC, 5A
|
|
Concept and functionThe PNI ST105 switching voltage supply converts the power supply from the 230 V AC mains into a DC DC DC voltage (13.8 V nominal) and supports a direct current of up to 5 A, with a peak of up to ~7 A. With this function, the device is suitable for powering electronic equipment that requires a 12 V DC power supply. |
Main Technical SpecificationsThe ST105 supports an input voltage of 230 V AC ±20% at 50 Hz, with an output of 13.8 V DC ±2%. The ripple (ripple voltage) is no more than 100 mVp-p, which indicates a low level of electrical noise. |
|
|
|
Advantages in use and typical applicationsThanks to its switching technology, the ST105 offers high efficiency and low losses, facilitating long-term stable operation with protection against overload and unstable voltages. It is ideal for applications such as CCTV systems, access control and other installations that require stable power supply at 12 V DC. |
Installation & SafetyInstallation is intuitive: connect the load to the output terminals (+ and -), after checking the polarity, then the unit is powered by the 230 V AC mains and switches to the ON position for switching on (LED indicates the operating status). It is recommended that the load be limited to ~80% of the rated current to ensure durability. In addition, it is necessary to install in a space with adequate ventilation, without blocking the cooling holes, and avoid exposure to moisture or dust, to prevent overheating or malfunctions. |
|
Video presentation |
|
PNI ST105 |
| Product Identification | |
| Product code | PNI-ST105 |
| Manufacturer | NIP |
| Features | |
| Input voltage | 230V AC |
| Input Signal Frequency | 50Hz |
| Output voltage | 13.8VDC ± 2% |
| Output Current | 5A continuous, 7A maximum |
| Operating temperature | -26°C ~ +80°C |
| Dimensions (D x H x W) / Weight | 205 X 115 X 82 mm |
| Output connectors | Plus(+), Minus(-) |
| The package contains | |
| Power Supply | Yes |
| User Manual | Yes |
