PNI voltage inverter L1200W power supply 12V 230V output

PNI voltage inverter L1200W power supply 12V 230V output
£80.67
Availability: In stock
SKU
PNI-H1200W12

CONNECTIONS

220V socket and USB output

The PNI L1200W inverter is equipped with a socket with an output of 230 V alternating current, modified sine wave for powering any electrical device, but also with a USB socket for charging, respecting the technical indications and the maximum allowed consumption.

Multiple applications

The inverter can be used to power various electrical devices with resistive load such as: televisions, lighting lamps, radios, fans, mini-fridges, power supplies, as well as for charging compatible devices via USB cable: smartphone, mp3, tablet, etc.

Applications

warnings

Operating status warning

The status LEDs of the PNI L1200W inverter warn you of the presence of error situations such as a discharged vehicle battery, overheating or overcharging of the device or will indicate its connection status to a power source.

Compatibility

The inverter can be used in any vehicle because it is designed to transform the voltage supplied by a 12 V battery into 230 V 50 Hz voltage. It is only used connected directly to the car battery.

feeding

Overheating protection

The aluminum housing of the inverter and the built-in fan allow extremely efficient passive and active cooling, and operation at maximum capacity all the time.

Incompatible with solar panels

Car inverters cannot be used with solar panels. There are special inverters for solar systems.

solar panel

Video presentation

PNI L1200W power inverter video presentation

Write Your Own Review
You're reviewing:PNI voltage inverter L1200W power supply 12V 230V output
Your Rating
Product identification
Model For resistive loads
Product code PNI-H1200W12
General characteristics
Power output 1200 W continuous
Peak output power 2400W for 0.1S
Input voltage 12V DC
Output voltage 230V AC
Amperage on the 230V output 0-5.2A
Active cooling With fan
Recommended cable size min 4mm
Output current (continuous) 6 A
Maximum output current (for a short time) 10
Maximum output power 2400W (for a short time)
Efficiency 85%
USB port output 5V / 1000mA
Output waveform Modified sinusoid
size 208 x 107 x 70 mm
Weight 1914 g
Alarms and protections
Overload protection Yes
CONNECTIONS
230 V socket 1 outlet
USB 2.0 Yes
The package contains
inverters Yes
Power cord Yes



PNI-H1200W12
Lang Type Name Link
EU Declaration of Conformity Declaratie de conformitate EN, ES, HU, IT, PL, RO Link
EU10 Declaration of Conformity Declaration of conformity EU9 Link
EU10 User manual User manual EU10 Link
RO Declaration of Conformity DC&CG Link
