PNI House WiFi660 NVR Video Surveillance Kit Package 8 channels and 8 wireless outdoor cameras 3MP, P2P, IP66
PNI-WF660 - PNI House WiFi660 NVR 8-channel video surveillance kit and 4 3MP, P2P, IP66 wireless outdoor cameras
Access and control methodsThe PNI House WiFi660 video surveillance kit can be controlled locally or remotely from mobile devices via the XMEye application compatible with Android and iOS, and from a PC via the General CMS software. The CMS software installation file can be found on the CD included in the package or can be downloaded from our website, on the product page, Download section.
| |
Wireless communicationYou can connect the camera to the internet via a wireless network. Also connect the camera to the NVR also via a wireless connection. The maximum WiFi transmission distance is 100 m (in open field). |
|
| 4 exterior roomsThe PNI House WiFi660 kit contains a recording unit (NVR) and 4 cameras, which can be used both indoors and outdoors, allowing you to monitor your home or business from anywhere you have an internet connection. |
8-channel NVRWith the NVR in the package you have the possibility to record and play images from 8 full HD video surveillance cameras (4 included in the kit + 4 purchased separately) . To record images, you can mount an internal HDD with a capacity of up to 6TB inside the NVR. |
|
| Night recordingThe 4 cameras are each equipped with 4 IR+FloodLight LEDs, which provides you with quality nighttime filming at distances of up to 30 m. |
Internet controlNow you can remotely watch in real time the images taken by PNI House WiFi660 . We also add full access to the system that allows you: settings, viewing recordings, downloading recordings, etc. Another advantage in this case is that the NVR in the kit can be accessed remotely via the internet via a P2P connection without requiring special configurations in your router. For Android and iOS we recommend the Xmeye application. |
|
| Real-time viewingWith the evolution of surveillance systems, HDD manufacturers have created dedicated solutions for them. Thus, for maximum performance of surveillance systems, we recommend using only hard drives dedicated to surveillance systems. |
PNI-ST1000VX005 - Internal Hard Disk Seagate SkyHawk HDD 1TB CCTV ST1000VX005
See more. Store more.Optimized for DVRs and NVRs, SkyHawk storage devices are tuned for 24x7 recording in capacities up to 10TB. Equipped with enhanced ImagePerfect firmware, SkyHawk helps minimize dropped frames and downtime, with a workload 3x higher than a PC hard drive, and is ready to record up to 90% of the time while supporting up to 64 HD cameras. | |
SkyHawk SmartThe innovative ImagePerfect firmware delivers smooth, clear video streaming for 24/7 surveillance environments - helping to ensure your business can always have a formidable level of protection. | |
SafeGive yourself ultimate peace of mind with SkyHawk surveillance devices and never miss a frame, even in harsh environments. SkyHawk’s extreme workload rating, low power consumption, and NVR-ready design can enhance long-term reliability. SkyHawk can also operate safely in operating temperatures—from 0°C to 70°C—while shock-resistant components provide additional protection in the field. |
Video presentation |
|
PNI House WiFi660 NVR 8 channel video surveillance kit EN |
PNI-WF660 - PNI House WiFi660 NVR 8-channel video surveillance kit and 4 3MP, P2P, IP66 wireless outdoor cameras | |
|---|---|
| Product identification | |
| Producer | NIP |
| Product code | PNI-WF660 |
| Color DVR/NVR | Black |
| Room color | White |
| DVR/NVR Features | |
| Video inputs | 8 entries |
| Video outputs | 1 x VGA, 1 x HDMI |
| Playback resolution | 1080P Full HD |
| Recording resolution | 4x5MP / 8x3MP |
| Audio outputs | 1 x 3.5mm |
| Registration type | Simultaneous audio and video recording |
| Audio compression | G711A |
| Video compression | H.265+ |
| Data storage | maximum 1 x 6 TB HDD (not included) dedicated to video surveillance |
| Network interface | RJ45 10/100Mbps |
| Firmware update | Yes, via USB |
| Supply voltage | 12V/2A |
| Operating temperature | -26°C ~ +80°C |
| size | 255 x 210 x 42 mm |
| Number of channels | 8 |
| Recording resolution and number of channels, variants | 8 3MP IP channels 4 5MP IP channels |
| PTZ control | Support |
| Wifi | Yes, only for connecting cameras |
| Wireless communication distance | Up to 100m in open space |
| USB ports | 2 x USB2.0 |
| Dedicated application | XMEye |
| Registration methods | Manual, Scheduled, Motion Detection |
| Motion detection | Yes |
| Face detection | Yes |
| Room features | |
| Image sensor | 1/2.7" CMOS 3.0 MP |
| Video system | PAL/NTSC |
| PIXEL | 2304 x 1296 |
| Minimum lighting | 0.1Lux/F1.2 |
| Degree of protection | IP66, metal housing |
| IR illumination distance | Up to 30 m |
| size | 65 x 175 x 58 mm |
| Number of IR LEDs | 4 IR LEDs and Floodlight |
| feeding | 12V / 1A |
| LENS | 4mm |
| Network interface | RJ45 10/100Mps |
| Wifi | Yes |
| Operating temperature | -26°C ~ +80°C |
| Dedicated application | XMEye |
| Sensor resolution | 3MP |
| The package contains | |
| DVR/NVR | Yes |
| Surveillance cameras | 4 indoor/outdoor rooms |
| NVR/DVR power supply | 230V -> 12V 2A |
| Software CD | Yes |
| User manual | Yes |
| USB mouse | Yes |
| Camera power supply | 230V -> 12V 1A |
PNI-IP660MP - PNI IP660MP 3MP video surveillance camera, wireless, with IP, outdoor and indoor, only for PNI House WiFi660 kit | |
|---|---|
| Product identification | |
| Producer | NIP |
| Product code | PNI-IP660MP |
| Color | White |
| Image sensor | |
| Image sensor | 1/2.7” Q03 CMOS |
| Sensor resolution | 3MP |
| Resolution | 2304x1296px |
| Lens type | 4mm |
| Minimum lighting | 0.1 Lux @ F1.2 |
| Audio | |
| Audio compression | G.711 |
| Network | |
| Ethernet | Yes, 10/100Mbps RJ-45 |
| General features | |
| LED | 4 IR LEDs and Floodlight |
| size | 65 x 175 x 58 mm |
| Net weight | 310 grams |
| IR distance | up to 30 m |
| P2P | Yes |
| Dedicated application | XMeye |
| feeding | |
| Supply voltage | 12V / 1A |
| The package contains | |
| Chamber | Yes |
| Wireless antenna | Yes |
| User manual | Yes |
| Fixing screws | Yes |
| Operating parameters | |
| fitting | Outside |
| Protection class | IP66 |
| Operating temperature | -26°C ~ +80°C |
