PNI DF930 video intercom with 1 monitor, 7 inch LCD screen, 800x480, electromagnetic yala output, black

Be the first to review this product

£59.29

Availability: In stock

SKU

PNI-DF930

Details

	Audio and video monitoring The PNI DF930 video intercom has a monitor with a resolution of 800 x 480 pixels, a 7-inch diagonal and a camera with a resolution of 700 TV lines. With a modern design and made of quality materials, the PNI DF930 offers its users multiple functions, which allow them to customize the contrast and brightness of the screen, as well as adjust the volume and choose the ringtone melody.
Two-way communication The intercom works as a closed-circuit video monitoring system, in which the outdoor unit transmits images to the monitor inside the house. In addition to video monitoring, the intercom also allows two-way communication between the indoor and outdoor units. The maximum operating distance is up to 100 m.
	Night vision The external unit of the PNI DF930 intercom is equipped with 6 infrared LEDs, which allows image capture even in very low light conditions. The video camera, with a resolution of 628 x 582 pixels and 420 TV lines, 3.6 mm lens and a viewing angle of 90 degrees, is protected from rain by a shield positioned in the upper area of the housing.
Electromagnetic yala connection The indoor unit offers you the possibility to unlock the electromagnetic doorbell connected to the intercom (outdoor unit) when you allow the visitor access to the premises. The intercom (gate unit) has a COM-NO (non-energized) output connection dedicated to Fail Secure electromagnetic doors with 12V DC impulse. Attention: to control the 12V impulse doorbell you also need a PNI K80 power supply which is purchased separately.
	Complete package The product comes with all the components and accessories included to be put into operation: indoor screen unit, gate unit with camera and button, power supply, 2 wall mounting brackets, mounting screws, installation and user manual.
Fast and intuitive connections To support installers and customers with technical inclinations and passions, the connections on the 2 units are plug&play, and can be made quickly thanks to the markings and numbering of the pins.

Reviews

Technical specifications

Product Identification
Manufacturer	NIP
Product code	PNI-DF930
Color	Black
General characteristics
LCD screen	Yes, 7"
Screen Resolution	800 x 480
Electromagnetic yala actuation output	From: Dry contact (COM/NO relay not energized)
Intercom	Yes
Outdoor monitoring	Yes
Power supply	12V/2A
Connection to the external unit	4-wire cable
Monitor Dimensions	210 x 20 x 150 mm
Outdoor unit dimensions	126 x 56 x 33 mm
Weight	650 g
Working temperature	-26°C ~ +60°C
Camera sensor	CMOS
Night Visibility	White/Black up to 3 m
Dimensions/Weight	Outdoor unit: 126 x 56 x 33 mm / 190 gr Indoor unit: 235.5 x 165.5 x 32 mm / 540 gr
Power supply	Power supply 230V - 12V DC / 2A
The package contains
Outdoor unit	Yes
Indoor unit (monitor)	1 monitor
Wall bracket for monitor	Yes
Fixing accessories	Yes
Indoor monitor power supply	Yes
User Manual	Yes
Cable connections
