CB PNI S9 antenna with butterfly, spike length 120 cm, without cable, 600W, 26-28MHz

High power CB antenna and broadband for cars and trucks.

£15.23

Availability: In stock

SKU

PNI-S9

	CB antenna performance The performance of the product is closely related to the technical characteristics of the antenna in ideal conditions of installation and use: SWR <= 1.2:1, maximum applied power 600 W, impedance 50 Ohms, stainless steel, etc.
Communication distance The communication distance is another decisive factor in the purchase and use of a CB antenna. Thus, the communication distance of 12-14 km is achieved in ideal working conditions: calibrated antenna, open field without obstacles, the station with the maximum legally allowed power of 4W and with a standard reception. Any obstacle such as: hills, mountains, buildings, walls can reduce this distance.
	Antenna length The length of the antenna is another very important factor that can influence the communication distance in traffic. Thus, the longer the antenna, the greater the range of action. PNI S9 has a length of 120 cm.
Adjustable angle This antenna can be tilted with the help of the butterfly screw with which it is provided, to enter passages, garages or low-height parking lots. Apart from these situations, an inclination greater than 30 degrees is not recommended because it can affect the performance of the antenna.

Video presentation
CB PNI S9 antenna with butterfly, spike length 120 cm, without cable, 600W, 26 28MHz UK

Product identification
Product code	PNI-S9
Work tape	? B
Product color (spike)	Silver
General characteristics
Working frequency	26 - 30 MHz
Number of channels	90
Maximum power applied	600W
Minimum SWR in the center of the band	less than 1.2:1
Length	120 cm
Impedance	50 Ohms
Material	Stainless steel
Connector type	your
Hole diameter	12.5 mm
Weight	280 g
size	131 x 10 x 3 cm
Operating temperature	-26°C ~ +80°C
The package contains
Radio station antenna	Yes
Plug PL259
Butterfly screw	Yes
Magnetic base
