PNI ML75 CB antenna, 75 cm, 300W, foldable and PNI SWR-300 reflectometer for SWR measurement, black
PNI-ML75FC - PNI ML75 CB antenna, length 75cm, 26-28MHz, 300W, foldable, without accessories
| CB antenna without cableThe PNI ML75 CB antenna operates in the 26-28 MHz frequency range. It is 75 cm long and can communicate over a distance of up to 8 km (under ideal conditions of use). The PNI ML75 is perfect for drivers of TIRs, trucks or cars who want a product that ensures good communication in traffic. The SWR of less than 1.2:1 and the maximum power supported of 300W (for a short time) are essential specifications that recommend this product to the most demanding users. |
PL type thread antennaWhen choosing a CB antenna, the following aspects must be considered:
The CB antenna is very important in the station - antenna assembly because the quality of the transmitted and received signal depends on it. The PNI ML75 CB antenna is one of the few PL antennas that can be tilted 90 degrees to enter passages, garages or low-height parking lots. |
|
| Compatible NIBP accessoriesThe PNI ML75 CB antenna with ø16mm thread is compatible with all PL type magnetic bases. For example: PNI 145/PL and with fixed mounting supports:
|
PNI-ML75FC - PNI ML75 CB antenna, length 75cm, 26-28MHz, 300W, foldable, without accessories | |
|---|---|
| Product identification | |
| Product code | PNI-ML75FC |
| Work tape | ? B |
| Product color (spike) | Silver |
| Coil color | Black |
| General features | |
| Working frequency | 26 - 28 MHz |
| Maximum applied power | 40 W continuous / 300 W for a short time |
| Minimum SWR in the center of the band | less than 1.2:1 |
| Length | 750mm |
| Impedance | 50 Ohms |
| Material | Stainless steel |
| Connector type | PL |
| Hole diameter | 16 mm |
| Weight | 343 grams |
| size | 750 X 40 X 40 mm |
| Polarization | vertically |
| Working distance | 7 km |
| Operating temperature | -26°C ~ +80°C |
| tiltable | Yes, up to 90 degrees |
| The package contains | |
| Radio station antenna | Yes |
| Rubber support | Yes |
PNI-SWR300 - PNI SWR-300 PWR-SWR Meter reflectometer, for measuring SWR of radio antennas in the 26-30Mhz frequency and power of CB radio stations | |
|---|---|
| Product identification | |
| Product code | PNI-SWR300 |
| General features | |
| SWR measurement | Yes |
| Power measurement | 0.5-10W / 10-100W |
| Accuracy | SWR ± 5% / POWER ± 10% |
| Frequency | 1.5-150MHz |
| size | 85 X 76 X 58 mm |
| Impedance | 50 Ohms |
| Connector | SO 239 |
| The package contains | |
| Reflectometer | Yes |
| User manual | Yes |
