Package Swing gate automation kit PNI MAB300, with 2 40W motors + PNI GA600 4G GSM relay

Swing gate automation system

The swing gate automation kit is equipped with two 40W motors with a maximum rotation speed of 200rpm that can open or close gates with a maximum weight of 200 kg and a maximum length of 2.5 meters. The PNI MAB300 gate automation kit includes the basic components needed to set up a practical access control system: control unit, two piston motors (maximum extension 300 mm), two remote controls, two photocells, warning light, rubber stop, and mounting accessory kit.

Remote control, compatible devices

The gate can be opened and closed from the remote control. The system supports the connection of other access control devices such as electromagnetic locks, electromagnets, access buttons, and access keypads. Optionally, the system can be connected to a solar system or a 24V backup battery.

Automatic closing with timer

The system can be set so that the gates close automatically after a certain period of time. The gates can also be opened or closed simultaneously or at a maximum difference of 10 seconds from each other, or only one gate can be opened at a time.

Obstacle detection

In the event of an obstacle being detected during opening or closing, the gates will stop. Choose safety for your family.

Installation diagram - dimensions

You can adjust the opening angle of the gate according to the dimensions in the table.

- D - desired opening angle

- A and B - values must be strictly observed on the same horizontal line with the angle to obtain the correct opening.

The values in columns A, B, C, E, and L are expressed in mm.

The values in column D are expressed in degrees.

The total length of the closed/open piston is indicated in the documentation, in the photo and in the manual.
