Wireless CB PNI Escort package HP 6500 ASQ + CB PNI ML70 antenna
Reduced dimensionsIts small dimensions (only 110x120x25mm) allow the station to be placed even in very narrow spaces, without having to resort to a real installation, as in the case of a classic CB. | |
Emission power 4WThe station complies with the legislation in force in Romania harmonized with European standards, having the maximum legal power allowed of 4 W. | |
FM/AMThe PNI Escort HP 6500 CB station allows communication in the FM band, used in Romania, but also in the AM band, when traveling abroad. In addition to the band type, the station also allows the selection of the frequency band, a setting necessary for using the station in other European countries. | |
Double squelch, adjustable and automatic digitalPNI Escort HP 6500 is improved with a digital automatic system for reducing noise and interference (Digital Automatic Squelch). The dual manual and automatic squelch mode offers 28 and 9-level adjustments along with the RF Gain function for a finer reception adjustment. | |
Performance CB antenna PNI ML70The performance of the product is closely related to the technical characteristics of the antenna in ideal installation and use conditions: SWR <= 1.2, maximum power applied 200 W, impedance 50 Ohms, stainless steel, etc. | |
Communication distanceThe communication distance is another decisive factor in the purchase and use of a CB antenna. Thus, the communication distance of a maximum of 9 km is achieved in ideal working conditions: calibrated antenna, open field without obstacles, the station with the legally permitted maximum power of 4W and with a standard reception. Any obstacle such as: hills, mountains, buildings, walls can reduce this distance. | |
Antenna lengthThe length of the antenna is a very important factor that can influence the communication distance. Thus, the longer the antenna, the greater the range of action. The PNI ML70 antenna is 70 cm long (magnetic base included). | |
Magnetic baseThe magnetic base PNI 145/PL in the package is provided with a 4 m cable, enough for placing the antenna on the dome, it has a diameter of 145 mm and a strong magnet that gives the antenna stability even at high speeds. |
Video presentation |
|
CB PNI antenna ML70, length 70cm, 26 30MHz, 200W, magnet 145 mm included EN |
Product identification | |
Product code | PNI-PACK61 |
General characteristics of the radio station | |
Model | Portable |
Emission band type | AM-FM |
Frequency | 26.965-27.405 MHz |
channels | 40 AM/FM |
Speaker audio power | 1W |
Sensitivity (20dB SINAD) | greater than 1 µV (AM/FM) |
Emission power | 4 W |
Modulation | 80 - 90% |
feeding | 12 V |
Consumption | 2A maximum |
Dimensions / Weight | 110 X 120 X 28 / 385 g |
Special radio station features | |
ASQ (automatic squelch) | |
Channel scan | Yes |
RF Gain | Yes, 9 levels |
Lock the keyboard | Yes |
Emergency channel button 9/19 | Yes |
ASQ adjustable | Yes, 28 levels |
SQ - Squelch | Yes |
Characteristics of the radio antenna | |
Working frequency | 26 - 28 Mhz |
Number of channels | 90 |
Maximum power applied | 200 W |
Minimum SWR in the center of the band | less than 1.2 |
Antenna length | 70 cm (magnetic base included) |
Working distance | 7 km |
Impedance | 50 Ohms |
Material | Stainless steel |
Connector type | PL259 |
Hole diameter | 16 mm |
Magnetic base included | Yes |
Magnetic base diameter | 145 mm |
Cable length | 4 m |
The package contains | |
CB radio station | Yes |
CB radio antenna | Yes |
Magnetic base | Yes |
Plug PL259 | Yes |
RG58 cable | Yes, 4 m |
