PNI Escort HP 5500 CB radio station, multistandard, 4W, AM-FM, 12V/24V, ASQ, RF Gain, cigarette lighter socket included
Simplicity for everyoneThe PNI Escort HP 5500 CB radio station is ultra compact, measuring only 115 X 115 X 35 mm it can fit even in the smallest spaces. Easy to install: just plug it into the cigarette lighter socket and outdoor CB antenna mounted on the car dome. The PNI Escort HP 5500 has been designed with simplicity in mind so that anyone can use it with ease. The high-quality electret condenser encapsulated in the microphone provides clear and powerful sound. | |
Important functions - anti-noise: SQ, ASQ and RF GainThe PNI Escort HP 5500 CB radio station allows the most faithful control over the background noise specific to the CB band. The adjustable analog SQ function with the potentiometer and 5-level ASQ allow the user to filter and remove noises making the communication clearer. The 7-level RF Gain function allows control over the receive frequency, reducing distortion. Other features of the PNI Escort HP 5500 station : emission power 4W, power supply 12-24V, 40 channels, AM/FM modulation, emergency channels 9-19, 6-pin connector for microphone, additional plug for external speaker. | |
Multistandard and multiband CB stationBy setting the rate and modulation, you can use the station in Great Britain (UK) and most European Union countries. The PNI Escort HP 5500 is equipped with the main European bands ( EU, CE, UK, PL, dE, in, i0, l2 ). NOTE, to change the norm: 1. Turn off the station; simultaneously press the PTT key + the UP key on the microphone while restarting the radio station 2. The LED corresponding to the A/F key lights up, and the current norm appears on the screen 3. Press the UP-DOWN keys to reach the desired rate, then restart the station or press the PTT key to exit the rate setting mode. |
Video presentation |
|
PNI Escort HP 5500 CB radio station EN |
Product identification | |
Producer | PNI |
Product code | PNI-HP5500 |
Product type | CB radio station |
General characteristics | |
Model | Portable |
Emission band type | AM/FM |
channels | 40 |
Frequency | 26.965 - 27.405 MHz |
Microphone type (pins) | 6 pins |
Speaker audio power | 3 W |
Sensitivity (20dB SINAD) | FM -120 dBm, AM -118 dBm@ SINAD 12dB |
Audio signal distortion | less than 5% @ 1KHz |
Emission power | 4 W |
Modulation | FM: 2 KHz, AM: 80% |
EEPROM memory | Yes |
feeding | 12 V / 24 V |
Dimensions (W x H x D / Weight) | 115 X 115 X 35 mm / 611 gr |
Special features | |
RF Gain | Yes |
ASQ | Yes, 5 levels |
ASQ adjustable | Yes |
Emergency channels | Yes |
Automatic Digital Squelch (ASQ) | Yes |
Manual squelch | Yes |
Accessory connection | 1 pin plug |
Operating temperature | -26°C ~ +80°C |
Screen lighting | |
Display type | LCD |
Rear panel connections | |
Additional speaker connection | Yes |
The package contains | |
Radio station | Yes |
Microphone | Yes |
Support and screws for holding the radio station | Yes |
Microphone support and screws | Yes |
Power cord | Yes |
Cigarette lighter plug | Yes |
User manual | Yes |
