PNI House AHD32LR Video Surveillance Camera, 2MP, 1080P, Outdoor IP66, 36 LED IR
Night time visibility
Thanks to the 36 IR LEDs, the PNI AHD32LR camera can also view at night up to a distance of 30 m. The metal housing ensures its resistance to water and dust, class IP66.
You can use the PNI House AHD32LR 2MP camera to monitor your home, offices, factories, shops, hospitals, etc. Simple, convenient and in real time.
AHD resolution (2MP) (Analog High Definition)
The AHD32LR analog camera has a resolution of 1920 x 1080px 2MP, offering clear images in real time.
Minimum illumination at night: color 0.1 Lux (F1.2, AGC ON) and black-and-white 0 Lux (IR LED ON)
The PNI AHD32LR camera is compatible with the PNI House PTZ1300 system and, in general, with systems that support AHD, TVI, CVI video signals.
The PNI House PTZ1300 hybrid system supports up to 4 5MP analog cameras or 16 1080P IP cameras or 8 5MP IP cameras or 4 5MP analog cameras and 2 1080P IP cameras.
The PNI AHD32LR camera is powered at a voltage of 12V/2A (the power supply is not included). For power supply, you can use the PNI 230V - 12V 1A Power Supply or the PNI 230V - 12V 5A Power Supply together with a 1x5 splitter to power several rooms.
Example assembly diagram
Package contents : surveillance camera, technical specifications brochure and instructions for use, dowels with screws for mounting.
|AHD video surveillance kit PNI House PTZ1300 Full HD - NVR and 4 outdoor cameras 2MP full HD 1080P||AHD video surveillance kit PNI House PTZ1500 5MP - DVR and 4 exterior cameras|
PNI House AHD32LR video surveillance camera, 2MP, 1080P, outdoor IP66, 36 IR LEDs UK
|Minimal lighting||0.01 Lux|
|Distance IR illumination||Up to 30 m|
|Number of LEDs||36|
|Video output||Analog, BNC connector|
|Supply voltage||12V / 1A|
|Image sensor||1/3" CMOS|
|size||63 x 166 x 63 mm|
|Use||Inside or outside|
|Image resolution||1920 x 1080 px|
|Cut IR filter||Yes|
|Operating temperature||-26°C ~ +80°C|
|Video signal type||AHD, TVI, CVI, CVBS|
|The package contains|
