PNI BP101S IR perimeter barrier with 2 beams, detection distance 150 m
| Advanced security systemThe PNI BP101S IR perimeter barrier is the ideal solution for protecting your property. Equipped with two IR beams, this barrier offers a detection distance of up to 150 m, ensuring extensive monitoring. Its robust PC resin design and IP65 protection make this product a reliable partner even in the most severe weather conditions. With low standby consumption and multiple alarm output options, it contributes to energy saving and the efficiency of security systems. |
Connectivity and performanceThe advanced technology of the PNI BP101S IR perimeter barrier ensures fast and precise detection, with a detection speed that can vary between 50-700 m/s. Thanks to protection against reflections, false alarms are significantly reduced, and the alarm triggering time is only 40 ms. The product offers NC/NO output connections, being compatible with most existing alarm systems. This allows you to easily integrate it into your security network. |
|
| Superior strength and durabilityWith an IP65 protection rating, the PNI BP101S IR perimeter barrier is water and dust resistant, ensuring optimal operation in the most varied environmental conditions. High-quality materials, such as PC resin, contribute to the durability of the product, providing protection against frost and condensation. This system is designed to stand the test of time, having all the necessary features to face external challenges. |
Practical usage scenariosThis perimeter barrier is perfect for various security applications, such as protecting private yards, commercial properties or industrial areas. It can also be used to secure the perimeter of temporary constructions, preventing unauthorized access. With effective detection over long distances, it is ideal for areas with a higher risk of intrusion. |
|
| Product identification | |
| Producer | NIP |
| Product code | PNI-BP101-S |
| Features | |
| Number of IR beams | 2 |
| Detection distance | 150 m |
| Supply voltage | DC 13.8-24V / AC 11-18V |
| Consumption | 35-50mA |
| Alarm output | NC/NO, DC 30V/0.5A |
| Tamper output | NC, DC 24V/0.5A |
| PROTECTION | Protection against interference caused by reflections (50000 LUX) Protection against frost and condensation. Water and dust resistance. False alarm protection. |
| Alarm trigger speed | 40ms |
| Detection speed | 50-700m/s |
| Optical axis adjustment angle | Horizontal: 180°(±90°), Vertical: 20°(±10°) |
| Material | PC resin |
| size | 85 x 75 x 170 mm |
| Water protection | IP65 |
| Package contents | |
| Perimeter barrier | Yes, 2 pcs. |
