CS202W PNI switch b

Touch buttons and tempered glass panel

PNI CS202W Dual Touch Ladder Head and Cross Head Switch can be operated by touching the touch buttons

The LED indicator shows the status of the lights (on - red LED, off - blue LED).

Capacitive touch front panel with fast touch response and scratch-resistant tempered glass also provides protection against electric shock if you touch the switch with wet hands.

Circuit head-ladder and head cross

The advantage of this switch is the ability to control a light source from two or more separate locations.

Suitable locations for installing such a switch are stairs, long corridors or bedrooms.

So imagine, it's late at night and you enter the bedroom. Press the door switch when you enter. Once you are in bed simply press the switch at the head of the bed to turn off the light i. The same applies to both sides of the bed and in this case for 2 separate lighting sources. The same principle applies to a long corridor or a large room with several entrances

switch PNI CS202W a

Switch PNI CS202W c

Head-ladder and head-ladder-cross-head

The PNI CS202W switch can operate both in head-ladder and head-ladder - head-cross mode.

Note: in ladder head - cross head mode, up to 8 single, double or triple switches can be connected in the same installation.

We recommend that the circuit breaker be installed by a qualified electrician.

Make sure that before installing the circuit breaker you have turned off the main fuse of the house. Follow all safety precautions to avoid personal injury and property damage.

Write Your Own Review
You're reviewing:Ladder head switch and double cross head switch with PNI CS202W glass touch, white with LED indicator, 800W / switch
Your Rating
Product identification
Producer PNI
Product code PNI-CS202W
General characteristics
Supply voltage 110-240VAC
Power output 800 W / switch
Maximum load supported 2000 W
Rated current max. 3.6 A
Consumption in stand-by 0.02W
Material Fire resistant glass / PC
Color White
size 86 x 86 x 35 mm
Weight 165 gr
Moisture 10% - 95%
Working temperature -26°C ~ +80°C
The package contains
Switch Yes, double
User manual Yes
Mounting screws Yes
