CB TTi TCB-550 EVO radio station kit + PNI ML145 antenna with magnet

CB TTi TCB-550 EVO radio station kit + PNI ML70 antenna with magnet, 70cm, 26-30MHz, 200W

CB radio station kit TTi TCB-550 EVO, VOX, NB filter, 12-24V with PNI ML160 antenna with magnet included

Be the first to review this product

£82.94

Availability: In stock

SKU

TTI-PACK57

Details

PNI-TCB-550EVO - CB radio station TTi TCB-550 EVO, DSS, VOX, NB filter, Scan, multicolor screen, 12-24V

	Always EVOLVING The new CB radio station TTi TCB-550 EVO brings several new functions and features compared to the previous model, including VOX which allows speaking into the microphone without pressing the PTT key, NB filter for clearer and distortion-free reception, multicolor screen and the possibility of 12V or 24V power supply.
Automatic tuning with DSS automatic squelch The TTi TCB-550 EVO CB radio station complies with current European standards and allows communication on the 40 channels in the 27 MHz band used for infotraffic. The station allows you to communicate in both types of bands: AM and FM. It is also equipped with a quick selector of emergency and international infotraffic channels, namely 9-19. .
	Ergonomic 4-pin microphone Radio communication is done in a simplex system using a microphone and a loudspeaker: - one speaks, and the others listen. By activating the VOX function, you can communicate without pressing the PTT key. The microphone is of normal size, easy to handle and is of the electret type with a 4-pin plug.
Ready to go You can use the product in any car, as it is one of the smallest CB stations on the market. Robust and with a pleasant design, it can be placed in any location: armrest, dashboard, between the seats, without being inconvenient or disturbing. The novelty of this model is the dual 12-24V power supply.

PNI-ML160FC - CB antenna PNI ML160, length 145 cm, 26-30MHz, 600W, without cable

PNI ML160 Performance

performances

The performance of the product is closely related to the technical characteristics of the antenna under ideal conditions of installation and use: SWR <1.1, Maximum applied power 600 W, impedance 50 Ohms, Stainless steel, etc.

Communication distance

The communication distance is another decisive factor in the purchase and use of a CB antenna. Thus, the maximum communication distance of 15 km or even more is achieved in ideal working conditions: Calibrated antenna, open field without obstacles, the station with the maximum legally allowed power of 4W and with a standard reception. Any obstacle such as: hills, mountains, buildings, walls can lead to a decrease in this distance.

PNI ML160 Communication distance

PN ML 160 Communication distance

Length

The length of the antenna is another very important factor that can influence the communication distance in traffic. Thus, the longer the antenna, the greater the communication distance / range. In this case 145 cm.

PNI-145-PL - Magnetic base PNI 145/PL 145mm contains 4m cable and PL259 plug

Magnetic base The PNI 145/PL magnetic base has a diameter of 145 mm, a size that gives the antenna stability even at high speeds, with a pleasant design.
	Threaded connection The PNI145/PL base is compatible with antennas that have an internal thread mounting system.
Cable length The length of the cable is an important factor in choosing a magnetic base. The PNI 145/PL base has a quality cable with a length of 4 m, which allows the antenna to be placed on the car's dome without any problems, and the cable to be placed so as not to disturb the passengers.
	Strong magnet The PNI145/PL base has a strong magnet for its size, which gives it a very good grip on the car's dome, and resistance and stability even at high speeds.
PL259 plug The PNI 145/PL magnetic base is equipped with RG58 coaxial cable and PL259 plug for direct connection to the station.
	Rubber support included To protect the car's dome from possible scratches, but without affecting the optimal functioning of the antenna, the 145/PL magnetic base is equipped with a thin and resistant rubber support, which also protects the connections and solders inside it from water.

Reviews

Technical specifications

PNI-TCB-550EVO - CB radio station TTi TCB-550 EVO, DSS, VOX, NB filter, Scan, multicolor screen, 12-24V
Product identification
Producer	TT
Product code	PNI-TCB-550EVO
Product type	CB radio station
General features
Exemplary	Furniture
Emission band type	AM/FM
channels	40
Frequency	26.965 - 27.405 MHz
Microphone type (pins)	4 pins
Speaker audio power	2W
Sensitivity (20dB SINAD)	0.7㎶ for 10dB (S+N)/N in AM mode / 0.7㎶ for 20dB SINAD in FM mode
Audio signal distortion	less than 8% @ 1KHz
Emission power	4W
Modulation	FM: 1.8KHz ± 0.2KHz, AM: 85-95%
EEPROM memory	Yes
feeding	12V / 24V
Dimensions (W x H x D / Weight)	135 X 125 X 35 mm / 767 g
Special features
Channel scan	Yes
ASQ	Yes
Noise filter	NB (Noise Blanker)
Multicolor screen	Yes, 3 colors
VOX	Yes
Manual squelch	Yes
TOT (Time out Timer)	Yes
Operating temperature	-10°C ~ +55°C
Screen lighting	Yes
Key illumination	Yes
Rear panel connections
Additional speaker connection	Yes
Bluetooth dongle connection	Yes
The package contains
Radio station	Yes
Microphone	Yes
Radio station mounting bracket and screws	Yes
Microphone holder and screws	Yes
Power cable	Yes
Cigarette lighter socket	Yes
User manual	Yes

PNI-ML160FC - CB antenna PNI ML160, length 145 cm, 26-30MHz, 600W, without cable
Product identification
Product code	PNI-ML160FC
Workband	? B
Product color (spike)	Silver
General features
Antenna type	5/8 lambda (λ)
Working frequency	26 - 30 MHz
Number of channels	90
Maximum applied power	600W
Minimum SWR in the center of the band	less than 1.2:1
Length	145 cm
Impedance	50 Ohms
Material	Stainless steel
Connector type	PL
Hole diameter	16 mm
Weight	280g
size	168 x 10 x 4 cm
Operating temperature	-26°C ~ +80°C
The package contains
Radio station antenna	Yes

PNI-145-PL - Magnetic base PNI 145/PL 145mm contains 4m cable and PL259 plug
Product identification
Product code	PNI-145-PL
General features
Sole diameter	145mm
Maximum speed	200 km/h
Weight	730g
Cable length	4 m
Compatible antenna type	With internal thread
size	15x15x6 cm
The package contains:
Magnetic base	Yes
Cable	Yes, 4m
jack	Yes, PL259

Download

PNI-145-PL

Lang	Type	Name	Link
EU10	Declaration of Conformity	Declaration of conformity EU10	Link
EU10	User manual	User manual EU10	Link

PNI-TCB-550EVO

Lang	Type	Name	Link
EU2	Declaration of Conformity	Declaration of conformity EN, RO	Link
EU2	User manual	User manual EN, RO	Link
