CBI Radio Station CBI ESCORT CB 8001L ASQ + CB PNI Extra 48 with Magnet

Be the first to review this product

£85.05

Availability: In stock

SKU

PNI-PACK39

Details

CB radio station PNI Escort HP 8001L ASQ includes headphones with HS81 microphone

Key lock switch

The PNI Escort HP 8001L CB radio station has a switch on the front panel that allows you to select the emergency channel (19), the normal operating mode (CH) and activate the key lock function (L) , a useful function in situations where you want to avoid accidentally touching the station keys.

Adjustable ASQ

An innovation in the CB segment, the adjustable automatic squelch (ASQ), offers maximum comfort even for the most demanding users of car CB radio stations. If until now we were used to activating/deactivating the ASQ, now PNI brings its adjustment function, a function that allows the elimination of up to 100% of interference, background noise and jamming in the CB band.

CB radio station PNI Escort HP 8001L ASQ includes headphones with HS81 microphone

6-pin microphone

The HP 8001L ASQ radio has a standard 6-pin microphone jack on the front panel. The included microphone has channel selection buttons, a PTT button, and an ASQ activation button.

40 channels

The PNI HP 8001L radio station complies with the latest European CB standards. The station has a switch for changing the modulation type (AM or FM) which will allow you to select the operating mode.

CB radio station PNI Escort HP 8001L ASQ includes headphones with HS81 microphone

HP 8001L ASQ

Headphone jack with microphone

The PNI HP 8001L radio station has jacks on the front panel for connecting a pair of headphones with microphone, included in the package.

Compatible with PNI Bluetooth accessories

The PNI Escort HP 8001L radio station is compatible with the PNI BT-Dongle 8001 Bluetooth adapter, the PNI BT-MIKE 8500 Bluetooth microphone and the PNI BT-MIKE 7500 Bluetooth headset.

CB radio station PNI Escort HP 8001L ASQ

Discreet and efficient

The PNI Extra 48 antenna is among the smallest CB antennas (it has a height of only 45 cm) and can be mounted on both cars and vans or minibuses. Its small dimensions make it almost unnoticeable, easily confused with a radio antenna. The average reception distance is 10 km.

CB antenna PNI Extra 45 with magnet included SWR 1.0

Anti-noise design

The PNI Extra 48 antenna has a special anti-noise design that allows air to slide around the spike, eliminating wind noise.

Reviews

Technical specifications

Product identification
Product code	PNI-PACK39
General characteristics of the radio station
Exemplary	Furniture
Emission band type	AM-FM
Frequency	26.965-27.405 MHz
channels	40 AM/FM
Microphone type	6 pins
Audio signal distortion	less than 5% @ 1 KHz
Emission power	4W
Modulation	FM: 1.8KHz ± 0.2KHz, AM: 85-95%
feeding	12V
Consumption	second
Dimensions / Weight	115 x 36 x 152 mm / 0.8 kg
Special features of the radio station
ASQ (automatic squelch)	Yes
Keyboard lock	Yes
Emergency channel button 9/19	Yes
Adjustable ASQ	Yes
Radio antenna features
Working frequency	26.965 - 27.405 MHz
Maximum applied power	150W
Minimum SWR in the center of the band	less than 1.2:1
Antenna length	45 cm (magnetic base included) Spike length: 44 cm
Working distance	10 km
Impedance	50 Ohms
Material	Fiberglass
Connector type	PL259
Cable length	4m
The package contains
CB radio station	Yes
CB radio antenna	Yes
Magnetic base	Yes

Download

PNI-PACK39

Lang	Type	Name	Link
EU	Declaration of Conformity	Declaratie de conformitate statie EN, BG, DE, ES, FR, HU, IT, PL, RO	Link
RO	Declaration of Conformity	DC&CG statie	Link
RO	User manual	Manual de utilizare statie	Link
